For a ride that's as thrilling as it is sleek!
Toyota
_
Tacoma
WHIPSAW
The HARTES METAL™ Whipsaw breaks from traditional bulky off-road wheels with numerous detailed, sharp spokes for a dynamic appearance.
WHIPSAW
Gloss Black
YSM-720
One-Piece Cast
Strength in numbers was the concept we chased after in developing the HARTES METAL™ Whipsaw. The idea behind this piece was to differentiate from the normal bulky spokes that are seen in most off-road wheels. Taking a closer look, one will notice the sharp details incorporated into each spoke making the wheel more dynamic overall.
Available Finish
Specification
Wheels Size, ET PCD, CB, Load Rate, Wight, and Cap
Size | H | PCD | ET | C/B | Cap | Load Rate | Weight |
|---|---|---|---|---|---|---|---|
20 x 10J | 10 | 114.3/127 | -18 | 78.1 | CP712PS184 | 2500 lbs | 42.1 lbs |
20 x 10J | 8 | 180 | -18 | 124.3 | CP708PS135 | 3700 lbs | 42.8 lbs |
20 x 10J | 8 | 165.1/170 | -18 | 125.2 | CP708PS113 | 3700 lbs | 42.1 lbs |
20 x 10J | 8 | 165.1/170 | -18 | 125.2 | CP712PS184 | 3700 lbs | 42.1 lbs |
20 x 10J | 12 | 135/139.7 | -18 | 106.1 | CP712PS184 | 2500 lbs | 41.7 lbs |
20 x 10J | 10 | 139.7/150 | -18 | 110.1 | CP712PS184 | 2500 lbs | 41.7 lbs |
22 x 12J | 8 | 165.1/170 | -44 | 125.2 | CP708PS113 | 3700 lbs | 52.7 lbs |
22 x 12J | 10 | 114.3/127 | -44 | 87.1 | CP712PS184 | 2500 lbs | 42.8 lbs |
22 x 12J | 8 | 170 | -44 | 125.2 | CP708PS113 | 3700 lbs | |
22 x 12J | 10 | 139.7/150 | -44 | 110.1 | CP712PS184 | 2500 lbs | 49.9 lbs |
22 x 12J | 8 | 180 | -44 | 125.2 | CP708PS135 | 3700 lbs | 52.7 lbs |
22 x 12J | 12 | 135/139.7 | -44 | 106.1 | CP712PS184 | 2500 lbs | 49.9 lbs |
22 x 12J | 8 | 180 | -44 | 124.3 | CP708PS135 | 3700 lbs | 52.7 lbs |
22 x 12J | 8 | 165.1 | -44 | 125.2 | CP708PS113 | 3700 lbs | |
22 x 12J | 10 | 114.3/127 | -44 | 78.1 | CP712PS184 | 2500 lbs | 42.8 lbs |
24 x 12J | 8 | 165.1/170 | -44 | 125.2 | CP708PS113 | 3700 lbs | 52.7 lbs |
24 x 12J | 10 | 114.3/127 | -44 | 87.1 | CP712PS184 | 2500 lbs | 42.8 lbs |
24 x 12J | 8 | 180 | -44 | 124.3 | CP708PS135 | 3700 lbs | 52.7 lbs |
24 x 12J | 12 | 135/139.7 | -44 | 106.1 | CP712PS184 | 2500 lbs | 49.9 lbs |
24 x 12J | 10 | 139.7/150 | -44 | 110.1 | CP712PS184 | 2500 lbs | 49.9 lbs |
24 x 12J | 8 | 170 | -44 | 125.2 | CP708PS113 | 3700 lbs | |
24 x 12J | 8 | 165.1 | -44 | 125.2 | CP708PS113 | 3700 lbs | |
24 x 12J | 10 | 114.3/127 | -44 | 78.1 | CP712PS184 | 2500 lbs | 42.8 lbs |
Specification
Wheels Size, ET PCD, CB, Load Rate, Wight, and Cap
Size | H | PCD | ET | C/B | Cap |
|---|---|---|---|---|---|
20 x 10J | 10 | 114.3/127 | -18 | 78.1 | CP712PS184 |
20 x 10J | 8 | 180 | -18 | 124.3 | CP708PS135 |
20 x 10J | 8 | 165.1/170 | -18 | 125.2 | CP708PS113 |
20 x 10J | 8 | 165.1/170 | -18 | 125.2 | CP712PS184 |
20 x 10J | 12 | 135/139.7 | -18 | 106.1 | CP712PS184 |
20 x 10J | 10 | 139.7/150 | -18 | 110.1 | CP712PS184 |
22 x 12J | 8 | 165.1/170 | -44 | 125.2 | CP708PS113 |
22 x 12J | 10 | 114.3/127 | -44 | 87.1 | CP712PS184 |
22 x 12J | 8 | 170 | -44 | 125.2 | CP708PS113 |
22 x 12J | 10 | 139.7/150 | -44 | 110.1 | CP712PS184 |
22 x 12J | 8 | 180 | -44 | 125.2 | CP708PS135 |
22 x 12J | 12 | 135/139.7 | -44 | 106.1 | CP712PS184 |
22 x 12J | 8 | 180 | -44 | 124.3 | CP708PS135 |
22 x 12J | 8 | 165.1 | -44 | 125.2 | CP708PS113 |
22 x 12J | 10 | 114.3/127 | -44 | 78.1 | CP712PS184 |
24 x 12J | 8 | 165.1/170 | -44 | 125.2 | CP708PS113 |
24 x 12J | 10 | 114.3/127 | -44 | 87.1 | CP712PS184 |
24 x 12J | 8 | 180 | -44 | 124.3 | CP708PS135 |
24 x 12J | 12 | 135/139.7 | -44 | 106.1 | CP712PS184 |
24 x 12J | 10 | 139.7/150 | -44 | 110.1 | CP712PS184 |
24 x 12J | 8 | 170 | -44 | 125.2 | CP708PS113 |
24 x 12J | 8 | 165.1 | -44 | 125.2 | CP708PS113 |
24 x 12J | 10 | 114.3/127 | -44 | 78.1 | CP712PS184 |
Accessories
Wheels Accessories Finsih
Gallery
Discover our gallery featuring wheels on Jeeps and pickups, illustrating their seamless integration and personalized style enhancements tailored for these vehicles.
